NVIDIA RTX A5000 Specs, Price and More

Check out the technical specifications of NVIDIA RTX A5000 graphics card in this article, along with its price and more.

Nvidia has recently released its new line of the graphics card with the RTX 5000 model. The RTX 5000 video cards, under Ada Lovelace architecture, will succeed the RTX Axxx under Ampere architecture. These lineups of graphics cards are aimed at professionals, unlike the GeForce which mainly targets gamers. Now, there are many fans of the green team searching for all the information related to the Nvidia RTX A5000 GPU. In this article, we will list down the technical specs of the NVIDIA RTX A5000 graphics card below.

NVIDIA RTX A5000 Specs, Price

NVIDIA RTX A5000 Specs

Below you will find out the official technical specifications of the NVIDIA RTX A5000 graphics card.

NVIDIA RTX A5000 Technical Specs

  • GPU memory: 24GB GDDR6
  • Memory interface: 384-bit
  • Memory bandwidth: 768 GB/s
  • Error-correcting code (ECC): Yes
  • NVIDIA Ampere architecture-based CUDA Cores: 8,192
  • NVIDIA third-generation Tensor Cores: 256
  • NVIDIA second-generation RT Cores: 64
  • Single-precision performance: 27.8 TFLOPS5
  • RT Core performance: 54.2 TFLOPS5
  • Tensor performance: 222.2 TFLOPS6
  • NVIDIA NVLink: Low-profile bridges connect two NVIDIA RTX A5000 GPUs
  • NVIDIA NVLink bandwidth: 112.5 GB/s (bidirectional)
  • System interface: PCIe 4.0 x16
  • Power consumption: Total board power – 230 W
  • Thermal solution: Active
  • Form factor: 4.4” H x 10.5” L, dual slot, full height
  • Display connectors: 4x DisplayPort 1.4a7
  • Max simultaneous displays: 4x 4096 x 2160 @ 120 Hz, 4x 5120 x 2880 @ 60 Hz, 2x 7680 x 4320 @ 60 Hz
  • Power connector: 1x 8-pin PCIe
  • Encode/decode engines: 1x encode, 2x decode (+AV1 decode)
  • VR ready: Yes
  • vGPU software support: NVIDIA vPC/vApps, NVIDIA RTX Virtual Workstation
  • vGPU profiles supported: See the Virtual GPU Licensing Guide
  • Graphics APIs: DirectX 12 Ultimate, Shader Model 6.6, OpenGL 4.68, Vulkan 1.38
  • Compute APIs: CUDA 11.6, DirectCompute, OpenCL 3.0

The price of an NVIDIA RTX A5000 graphics card is $3,598.00 USD.

NVIDIA RTX A5000 Features

The Nvidia RTX A5000 graphics card features PCI Express Gen 4 with four DisplayPort 1.4a connectors. It also supports AV1 decode support along with DisplayPort with audio. The rest of the features of this card can is listed below:

  • 3D stereo support with stereo connector
  • NVIDIA GPUDirect® for Video support
  • NVIDIA virtual GPU (vGPU) software support
  • NVIDIA Quadro Sync II3 compatibility
  • NVIDIA RTX Experience
  • NVIDIA RTX Desktop Manager software
  • NVIDIA RTX IO support
  • HDCP 2.2 support
  • NVIDIA Mosaic technology

That is everything you need to know about the technical specs of NVIDIA RTX A5000 along with its price and features. In the meantime, do not forget to check out other guides only on our website TechNClub.com: Nvidia GeForce RTX 4080 vs RTX 4070 Graphics Card, and Nvidia GeForce RTX 3080 vs RTX 4070 GPU.
